Electric Hatch
One of our most popular products in two affordable standard sizes. Perfect for roof top entrance.
Details
-
ColourRAL 7016 grey / RAL 9010 inside
-
Frame materialAluminium
-
GlassHR++ glass
Size
-
Outside dimension1 x 2 meter (XL) and 1 x 3 meter (XXL)
-
Opening dimension800 x 1800mm (XL) and 800 x 2800mm (XXL)
Unique characteristics
-
Flush integration into the roof -
Sky Only View through minimal framework -
Excellent insulation due to double hardened and coated glass system with argon filling -
Easy installation
Electric hatch
Do you want an extra large hatch? This beautiful electric hatch, up to 1 x 3 meters, brings a lot of light into your home. The roof hatch not only gives comfortable access to your roof terrace, but also provides ventilation.
The Electric Hatch has a minimalist design: insulated glass in aluminum, the electronics and opening mechanisms are hidden in the frame, inside only the glass is visible: the Sky Only View.
Unique features
- Excellent insulation with thermally broken system
- Minimal design: mechanism hidden in the frame
- The roof hatch opens electrically
- Operation via smartphone possible
- Comfortable exit by opening to almost 90 degrees within one minute
- Easy installation
- Colour: RAL 7016 grey outside
Glass specifications: 28.8mm safety glass
- Outer: 6mm Clear HST tempered glass with a coating for increased thermal efficiency
- Spacer: 14mm Argon filled cavity
- Inner: 8.8mm Clear HST tempered glass
What does this mean?
- The glass is excellently insulated: comparable to HR++.
- The U-value is 1.1 W/m²K. This is due to the argon-filled cavity and the special e-coating that ensures less heat loss.
- The glass is extra strong due to the ‘Heat Soak Tested’ treatment.
- ZTA-value (also known as G-value) is 63%. This sun access factor means that 37% of the sun’s heat is blocked. Good for hot days.
Good to know
You can now buy the most popular sizes directly from the manufacturer. We keep these products in stock so that we can deliver quickly at the lowest rates. This way you get top quality for a good price.
The Electric Hatch falls over the upstand like a lid.
Specifications of the upstand:
- Minimum height: 150mm
- Width including weathering: 100mm
- Pitch: minimum 3 degrees
The dimensions on this webshop are always the outside dimensions of the upstand. This means that the opening seen from the inside is smaller.
The hatch XL of 1 x 2 meter has an inner size of 800 x 1800mm.
The hatch XXL of 1 x 3 meters has an inner size of 800 x 2800mm.
We can also make the Electric Hatch to measure.
The electric roof hatch comes with assembly equipment (kit, screws etc) and with an installation manual. Enthusiastic do-it-yourselfers also install our products themselves.
- 10-year warranty (see conditions)
- Available from stock
